In addition, the updated discharge reed valves have shot peening to improve the metal properties that increase the strength & durability of the valve.ģ. a new valve backer with a larger surface area for the discharge reed to contact, which is designed to better support the valve in the opening position, improving the life of the valve.Ģ. The primary failure mode is a broken discharge valve in the unloading cylinder bank.Ĭarlyle has issued an updated version of the valve plate which includes :ġ. Liebert has experienced an increasing failure rate of semi-hermetic compressors on these units with unloading. The 1st 2 digits are the week, and the next 2 digits are the year.

#Specialized airtool pump ol serial number#

The issues are with Liebert Deluxe & also DS 30 ton 4 step units containing Carlyle 06DF537 compressors with unloading that were shipped from MaOct 19, 2008.Īny compressor with a serial number of 4208 (1st 4 digits) or greater has the updated valve plate assembly, which means it should not have the problem. It had to be the top compressor of course. The only one I ever had to change out, on a Liebert, was due to an overfeeding TXV. In my experience, these have been very forgiving, reliable compressors. Since these are 6 cylinder compressors (3 heads) we must remove the compressors from their mounts and turn them 90 degrees in order to get to the back head to replace that valve plate.I'm curious as to the issues with the 06Ds. Since these are 6 cylinder compressors (3 heads) we must remove the compressors from their mounts and turn them 90 degrees in order to get to the back head to replace that valve plate. We've been finding broken valves on the unloading head and have also found a piston laying in the crankcase on one of them.

#Specialized airtool pump ol upgrade#

We are having to upgrade the valve plates.

We have several of these to work on due to a Carlyle issue. The lower compressor can be removed in the typical fashion, similar to your method, by sliding it directly onto my homemade unistrut platform that has sheet metal secured on the top of it. With the come-a-long at the center of that point, I slightly lift the top compressor out, then lower it onto a homemade unistrut platform that I place over the refrigerant piping. What I've been doing is securing two 12 foot lengths of double unistrut across the top of the units, and hooking a come-a-long from another piece of strut that spans across the the top of those two pieces. The piping for refrigerant, condensate, & electrical is in the way of placing a high jack or a tablelift in front of the compressors. The air discharges underneath the unit through a plenum and under the wall into the data room for underfloor air distribution. These units are not sitting on a data room floor like we typically find, but instead are in small rooms just outside the actual data room, sitting on the typical Liebert stands, so the units are about a foot and a half above the concrete floor in the rooms where they're located.
